250kw 9m3 Transit Mixer Truck Road Construction Machinery

Brand Name : XDEM

Model Number : G09ZZAL

Certification : CE ISO

Place of Origin : China

MOQ : 1 set

Price : USD50000-100000

Supply Ability : 500 sets per month

Delivery Time : 45 working days

Packaging Details : Nude

Type : New

Model : G09ZZAL

Brand of chassis : Sinotruck

Chassis model : ZZ1257N3847D1L(LNG)

urb weight : 14000 kg

Maximum gross weight : 25000 kg

Type of drive 8×4 Wheel base : 6×4

Wheel base : 3625+1350mm

Tyre : 12.00R20

Contact Now

XDEM G09ZZAL 9m3 Concrete Cement Mixer Truck, Hottest sell Concrete Mixer Truck in good price

Concrete Mixer Truck Main Configurations:

Type Model Unit G09ZZAL
Performance of mixing drum Geometric volume m³ 15.67
Mixing volume m³ 9
Maximum diameter of drum body mm 2380
Length of mixing drum mm 5101
Angle of inclination ° 13.5
Rotating speed r/min 0~14
Charge speed m³/min ≥3
Discharge speed m³/min ≥2
Residue ratio of discharge % <0.7
Range of slump cm 5~21
Hydraulic system Oil pump international brand
Motor international brand
Reduction gears international brand
Hydraulic circuit Closed type
Water supply water tank capacity L 450
Way of water supply Pneumatic
Complete machine Brand of chassis Sinotruck
Chassis model ZZ1257N3847D1L(LNG)
Type of driving Left-hand drive
Curb weight kg 14000
maximum gross weight kg 25000
Driving type 6×4
Wheel base mm 3625+1350
Tyre 12.00R20
Means of power takeoff Power takeoff by flywheel
Notice model XZJ5251GJBA1L
External dimensions (length×width×height)mm 9300×2500×3890
Engine Model T10.34-40
Rated power Kw/r/min 250
Displacement L 9.726
Emission standard GB IV

250kw 9m3 Transit Mixer Truck Road Construction Machinery

Company Information

We Nanyang Xinda Electro-Mechanical (XDEM), is an senior international trading company mainly dealing construction machinery, which was set up and supported by local dealer ship of XCMG, LIUGONG, we continually introduce Chinese excellent construction machinery enterprises and their products to international markets, such as XCMG, LIUGONG, SANY, YTO etc. We not only make more international customers know and approbate our products, but also gradually build up friendship with construction machinery customers all over the world.
We have the largest-size factories for construction machinery and industrial equipments in Asia. Our factories have the world-class modern facilities and automated manufacturing process for production. Our factories are mainly located in Jiangsu, Henan, Hubei provinces in China.
